 Uses
|
| .. |
管路与结构和舾装的干涉检查免除了生产的后顾之忧。三维短管图纸不仅可以自动生成而且可以自动标注尺寸，显著地减少了生产时间同时将错误降至最低。在任何时候，一个管道项目被创建、删除或者修改了，整个产品模型的重量和重心都会在不需用户干预的情况下马上更新。
TInterference checking against
structure and outfitting provides worry free production.
3D spool drawings are not only automatically generated,
but also automatically dimensioned and annotated
reducing time-to-production significantly and minimizing
errors. Naturally, anytime a pipe item is created,
deleted, or altered, the weight and CG of the complete
product model is updated immediately without user
intervention.
|
|
|
| .. |
Pipe--管道设计
Pipe模块和其它的ShipConstructor模块是完全融为一体的，它允许管道设计部门和其它部门同时工作、同时共享所有的数据。在一个带有说明和线路的合理的管道目录的基础上，可以很快的生成一个三维管道模型，同时可以参考任意数量的三维结构图纸以保证管路没有冲突。 |
|
| |
| ...Brief |
| .. |
Easily
design & check 3D piping in complex hull structure
Pipe
is fully integrated with the other ShipConstructor
modules allowing the pipe department to work in
parallel with other departments sharing all data
in real-time. Based on a logical pipe catalog
with specs and connections, a 3D pipe model can
be quickly generated, referencing any number of
3D structure drawings to ensure collision free
routing.
|
|
| |
|
